Hi Combo 3D Printer + CFS Multi System Box – multicolor printing up to 16 colors, 260×260×300 mm volume, 500 mm/s speed
Full technical specifications
Printing technology FDM / FFF
Print volume 260 × 260 × 300 mm
Typical print speed 300 mm/s
Maximum speed 500 mm/s
Maximum acceleration up to 12,000 mm/s²
Layer height (resolution) between 0.1 and 0.35 mm
Standard nozzle 0.4 mm (compatible with 0.6 / 0.8 mm)
Maximum nozzle temperature 300 °C
Maximum heated bed temperature 100 °C
Filament diameter 1.75 mm
Compatible materials Hyper-PLA, PLA, PETG, ABS, PLA-CF
Direct drive extruder with metal gears
Number of extruders 1
Automatic bed leveling
Filament run-out sensor
Filament tangle detection
Integrated monitoring camera
Vibration compensation system (input shaping)
3.2-inch color touchscreen
Connectivity USB, Wi-Fi
Internal memory 8 GB eMMC
Supported file formats G-code, 3MF
Recommended software Creality Print 5.1 or later
Operating system compatibility Windows, macOS, Linux
Multiple interface languages (English, German, Spanish etc.)
Power supply AC 100-240 V, 50 Hz
Rated power 1150 W (at 220 V) / 390 W (at 110 V)
Operating noise ≤ 48 dB
Printer dimensions 409 × 392 × 477 mm
Net weight 8.75 kg
Combined dimensions with CFS 650 × 460 × 560 mm
Total weight with CFS ~ 13.31 kg
CFS (Creality Filament System) specifications
CFS module dimensions 379 × 314 × 276 mm
Module net weight 4.56 kg
Supply voltage 24 V DC
Power 20 W
Number of supported filament spools 4
RFID filament recognition technology
Temperature and humidity display
Compatible filaments PLA, PETG, ABS, ASA, PA-CF
Supported spool slots Ø 197-202 mm, thickness 42-68 mm
General description
The Hi Combo with CFS offers automated multicolor printing capabilities, combining the power of the Hi printer with the CFS system. With a print volume of 260 × 260 × 300 mm and a maximum speed of 500 mm/s, this package allows for the creation of detailed and expressive objects in up to 16 colors simultaneously, if four CFS modules are used.
The CFS system manages filament and color changes automatically, recognizing filament via RFID and controlling humidity in the module. Automatic leveling, error detection and filament sensors ensure printing continuity, and vibration compensation maintains quality at high speeds. All these make the Hi Combo + CFS an integrated solution for designers, laboratories, SMEs, and digital centers.
Applications and fields of use
This package is ideal for creating multicolored objects, aesthetic prototypes, decorative models, architectural mock-ups, or functional parts with color codes. In education, it is useful for design, visual arts, or robotics courses with colored elements. For SMEs or startups, it offers a professional solution for customized products and branding without requiring manual post-processing.
Main advantages
Real multicolor printing capability up to 16 colors
Automatic leveling, filament detection, and automatic color change
Compatibility with technical materials
Stable structure, vibration compensation, and precise control
Complete hardware-software integration for efficiency and ease of use
